Acoustic perforated panels offer the design flexibility of perforated aluminium while helping control noise from rooftop plant and building services. Available in a range of perforation patterns and finishes, systems can be customised to complement the architectural language of the building.
| Perforation Pattern Options |
Multiple perforation patterns are available – refer to the product data sheet for standard options. Custom perforation patterns are also available to suit project-specific requirements. |
| Materials |
Perforated facing panels to front of screen wall are manufactured from aluminium sheet. Acoustic backing panels consist of a solid aluminium casing, high-density mineral wool core and woven stainless steel mesh lining. |
| Acoustic Performance |
|
| Surface Finish Options |
|
| Support Structure |
For smaller screen walls, Ventuer can provide a complete system including integrated support framing. For larger installations, screen walls are typically supplied with secondary support framing designed to fix back to the project primary structure by others. |
| Dimensions |
Perforated screen walls can be constructed to suit projects of virtually any overall size. Individual module dimensions are typically determined by site access, handling and installation constraints. Maximum module sizes vary depending on perforation pattern, material thickness, wind loading and support requirements. |
| Weight |
Typical system weight ranges from 10kg/m² to 20kg/m² depending on perforation pattern, aluminium thickness, support requirements and selected acoustic backing panel depth (55mm or 85mm). |
