The AL-600W provides an STC rating of 20 dB and high rain defence. Its 600mm depth makes it ideal for generator enclosures and data centres requiring high acoustic performance and weather protection.
| Dimensions |
Depth: 600mm Height: Minimum 450mm, Maximum 2400mm (panel modules can be spliced together to form larger louvres) Width: Minimum 300mm, Maximum 2400mm (panel modules can be spliced together to form larger louvres) |
| Blade Centres |
150mm |
| Rain Defence Performance (BS/EN 13030:2001) |
Class A - up to 0.5m/s suction velocity Class B - up to 1.5m/s suction velocity Class C - up to 2.0m/s suction velocity Class D - up to 3.5m/s suction velocity |
| Aerodynamic Performance (BS/EN 13030:2001) |
Air Inlet: 0.213, Class 3 Air Extract: 0.228, Class 3 |
| Sound Reduction Index (ISO 10140-2) | Frequency (Hz) | One-third Octave (dB) |
| 50 Hz | 7.4 dB 63 Hz | 6.1 dB 80 Hz | 4.7 dB 100 Hz | 4.3 dB 125 Hz | 6.5 dB 160 Hz | 6.1 dB 200 Hz | 7.1 dB 250 Hz | 7.3 dB 315 Hz | 8.5 dB 400 Hz | 12.4 dB 500 Hz | 15.3 dB 630 Hz | 19.4 dB 800 Hz | 24.8 dB 1000 Hz | 30.1 dB 1250 Hz | 35.6 dB 1600 Hz | 40 dB 2000 Hz | 42.7 dB 2500 Hz | 44.9 dB 3150 Hz | 45.2 dB 4000 Hz | 42.8 dB 5000 Hz | 39.1 dB |
|
| Geometric Free Area (active blades only) | 30% |
| Surface Finish Options |
Powdercoated Anodised Raw Aluminium (Mill) |
| Perimeter Frame Options |
Channel Frame Flanged Frame |
| Ancillaries Options |
Bird Mesh Insect Mesh Solid Blanking Perimeter Mounting Angle |
