The AL-600V delivers an STC rating of 22 dB at 600mm depth, ideal for open-topped plant screens in data centres and hospitals where rain defence is unnecessary.
| Dimensions |
Depth: 600mm Height: Minimum 450mm, Maximum 2400mm (panel modules can be spliced together to form larger louvres) Width: Minimum 300mm, Maximum 2400mm (panel modules can be spliced together to form larger louvres)
|
| Blade Centres |
150mm
|
| Rain Defence Performance (BS/EN 13030:2001) |
Class B - up to 0.5m/s suction velocity Class C - up to 1.5m/s suction velocity Class D - up to 3.5m/s suction velocity
|
| Aerodynamic Performance (BS/EN 13030:2001) |
Air Inlet: 0.224, Class 3 Air Extract: 0.224, Class 3
|
| Sound Reduction Index (ISO 10140-2) | Frequency (Hz) | One-third Octave (dB) |
|
50 Hz | 9.8 dB
|
|
| Geometric Free Area (active blades only) |
30%
|
| Surface Finish Options |
Powdercoated Anodised Raw Aluminium (Mill)
|
| Perimeter Frame Options |
Channel Frame
|
| Ancillaries Options |
Bird Mesh Insect Mesh Solid Blanking Perimeter Mounting Angle
|
